PCR43302RE 2 Channel 433 MHz Penta Receiver - Enclosed Case
The PCR43302RE is the enclosed-case version of Elsema's 2-channel 433 MHz Penta receiver with relay outputs. It runs from 12 to 24 V AC or DC, supports frequency hopping and Penta dual coding, and provides two changeover relay outputs rated at 10 A at 240 V AC.
For gate, door, lighting, security shutter and automation control, the enclosed format gives a neater receiver option while retaining the same flexible output behaviour as the board version. Installer-selectable modes include momentary, latching, delayed-off, on-off, roller-shutter and security latching functions.
Key Features
- Enclosed construction suits installations where a finished receiver housing is preferred.
- Two relay channels give practical control scope for paired or separate switching tasks.
- Selectable output modes help match the receiver behaviour to the application rather than forcing one control style.
- Compatibility with PentaFOB and PentaCODE remotes supports use within the Penta remote ecosystem.
- Compact case dimensions make it suitable for access-control and automation locations with limited mounting space.
- Catalogue Family:
- TRANSMITTERS & RECEIVERS
- Supply Voltage:
- 12 to 24 V AC or DC
- Standby Current:
- 21 mA at 24 V DC
- Frequency Band:
- 433.100 to 434.700 MHz
- Operating Temperature:
- -5 to 50 deg C
- Receiver Memory:
- Unlimited remotes
- Decoding System:
- Encrypted 17 billion code combinations or on-board 12-way code switch
- Outputs:
- Two changeover relay outputs rated at 10 A at 240 V AC
- Relay Contacts:
- Common C Normally Closed NC and Normally Open NO
- Connections:
- Supply and output via 8-way female connector
- Dimensions:
- 136 x 85 x 33 mm
- Weight:
- 145 g
- Usable Transmitters:
- FOB433 series and PCK series
- Product Type:
- Transmitters & Receivers
