IXW-MA Aiphone Multi-Purpose Adaptor - 4 Contact Inputs 10 Relay Outputs
The IXW-MA is an Aiphone multi-purpose adaptor for adding low-voltage input and relay-output points to a networked intercom installation. It connects by Cat-5e/6 LAN/PoE through an IEEE 802.3af PoE switch and provides four programmable dry-contact inputs with ten dry-contact relay outputs.
It suits indoor installations where intercom system events need to interface with external low-voltage control or signalling circuits. The adaptor supports 3-gang box mounting, PE 0.65 mm low-voltage wiring guidance and orange/blue status indication for installation, standby and fault checks.
Key Features
- Expands a networked intercom installation with dedicated input and relay control points.
- PoE network connection supports installation without a separate local power supply at the adaptor.
- Programmable dry-contact inputs help accommodate site-specific trigger requirements.
- Form C and Form A relay groups provide flexible output options for connected low-voltage circuits.
- Status indication and reset access support setup, service checks and fault identification.
- Catalogue Family:
- INTERCOM
- Product Type:
- Intercom
- Network Connection:
- Cat-5e/6 straight-through cable to LAN/PoE
- PoE Standard:
- IEEE 802.3af
- Network Cable Distance:
- 100 m (330 ft)
- Contact Inputs:
- 4 programmable dry-contact inputs
- Input Method:
- Programmable dry contact N/O or N/C, level detection method
- Input Detection Time:
- 100 ms or more
- Contact Resistance:
- Make: 700 Ohm or less; Break: 3 kOhm or more
- Input Terminal Voltage:
- 5 V DC or less between open terminals
- Relay Outputs 1 to 4:
- Form C dry contact closure, N/O or N/C
- Relay Outputs 5 to 10:
- Form A dry contact closure, N/O
- Relay Contact Rating:
- 24 V AC/DC, 0.5 A resistive load
- Recommended Low-Voltage Wiring:
- PE 0.65 mm (22 AWG)-2C
- Mounting:
- 3-gang box, indoor use only
