JACKFUSE

ATMOD GREEN 2K/2K RESISTOR

SKU: JKFATMOD22 Supplier SKU: ATMOD22
Width:
7.00 (cm)
Height:
8.00 (cm)
Depth:
24.00 (cm)
Minimum Purchase:
48 units

KEY FEATURES

Product Downloads

Description
Download
ATMOD22 Datasheet
ATMOD22 Installation Manual

Please Note: Minimum order quantity (MOQ) 48 units.

ATMOD22 Advanced Termination Module 2K2/2K2 EOL Resistor Pack - Green

The ATMOD22 Advanced Termination Module is a green, pre-built 2K2/2K2 end-of-line (EOL) resistor pack for security and access control circuits. Its PCB-mounted surface-mount resistors and quick-connect spring-clamp terminals create a compact termination solution for standard security cables, with an orientation tab identifying the end that connects to the alarm device.

Listed for Integriti and Inception systems, the ATMOD22 suits new alarm and access control installations, replacement of existing resistor networks and system upgrades. Its compact insulated construction fits inside most alarm devices, door frames and duct, while workshop pre-termination can streamline site work for reed switches, electric locks, exit buttons and other field devices.

Key Features

  • Reduces installation time by replacing hand-built EOL resistor networks with a pre-assembled module
  • Makes the correct resistor configuration and circuit orientation easier to identify
  • Enables workshop pre-termination for more efficient site installation
  • Keeps EOL circuitry compact and concealed close to the monitored device
  • Reusable connection design simplifies later servicing or system changes
Catalogue Family:
TOOLS & INSTALLATION ACCESSORIES
Product Type:
RESISTOR MODULE
Resistor Value:
2K2/2K2
Colour:
GREEN
Minimum Conductor Size:
0.2 mm2 stranded (24AWG)
Maximum Conductor Size:
0.5 mm2 (20AWG)
Dimensions:
24 L x 7 W x 8 H mm
Application:
SECURITY ALARM AND ACCESS CONTROL EOL RESISTOR CIRCUITS
Country of Origin:
China
Series:
ATMOD
Features:
2K2/2K2
