ATMOD WHITE 180/300 OHM RESISTOR

SKU: JKFATMOD18 Supplier SKU: ATMOD18
Width:
7.00 (cm)
Height:
8.00 (cm)
Depth:
24.00 (cm)
Minimum Purchase:
48 units

KEY FEATURES

Product Downloads

Description
Download
ATMOD18 Datasheet

Please Note: Minimum order quantity (MOQ) 48 units.

ATMOD18 ATMOD End-of-Line Resistor Module - 180Ω/300Ω White

The ATMOD18 is a Jack Fuse ATMOD quick-connect end-of-line resistor module featuring a pre-built 180Ω/300Ω resistor network for PCSC security and access control applications. Its surface-mount PCB, push-in spring terminals and white colour-coded insulation are combined in a compact module.

Suitable for new installations, replacement of older resistor networks and system upgrades, the ATMOD18 supports concealed placement inside or close to compatible alarm devices. A dedicated tab identifies the alarm-device end, helping installers orient the module correctly during termination.

Key Features

  • Allows compatible field devices to be pre-fitted in the workshop for more efficient onsite installation
  • Reduces orientation errors with a tab marking the connection to the alarm device
  • Accepts stripped alarm cabling directly to minimise additional termination tools
  • Maintains conductor pressure through spring-clamp terminal blocks
  • Supports practical service changes by allowing conductors to be removed and the module reused
LIMITED LIFETIME
Catalogue Family:
TOOLS & INSTALLATION ACCESSORIES
Product Type:
RESISTOR MODULE
Resistor Value:
180/300 ohm
Colour:
WHITE
Minimum Conductor Size:
0.2 mm2 stranded (24AWG)
Maximum Conductor Size:
0.5 mm2 (20AWG)
Dimensions:
24 L x 7 W x 8 H mm
Compliance References:
RoHS compliant; AUS/NZ (RMC-EMC) 61000.6.3 compliant
Primary Materials:
Polyamide 46, fiberglass, polyolefin
Country of Origin:
China
Series:
ATMOD
Features:
QUICK-CONNECT, PUSH-IN TERMINALS
