ATMOD RED 10K/10K RESISTOR

SKU: JKFATMOD10 Supplier SKU: ATMOD10
Width:
7.00 (cm)
Height:
8.00 (cm)
Depth:
24.00 (cm)
Minimum Purchase:
48 units

KEY FEATURES

Product Downloads

Description
Download
ATMOD10 Datasheet
ATMOD10 Installation Manual

Please Note: Minimum order quantity (MOQ) 48 units.

ATMOD10 ATMOD End-of-Line Resistor Module - 10K/10K Red

The ATMOD10 is a Jack Fuse ATMOD quick-connect end-of-line resistor module for security alarm and access control systems. It combines a pre-built PCB with surface-mount 10K/10K resistors, push-in spring terminals and red colour-coded insulation in a compact module.

Designed for new installations, replacement of older resistor networks and system upgrades, the ATMOD10 can be terminated to standard security cable and device fly leads. Its orientation tab identifies the alarm-device end, while the compact insulated construction suits installation inside most alarm devices, door frames and ducting.

Key Features

  • Simplifies connection because polarity does not need to be observed at either end
  • Supports workshop pre-fitting to compatible field devices for more efficient onsite installation
  • Helps prevent wiring errors with a tab that clearly identifies the alarm-device end
  • Maintains conductor pressure through spring-clamp terminals across supported wire sizes
  • Accommodates common alarm cabling and device fly leads for flexible field termination
LIMITED LIFETIME
Catalogue Family:
TOOLS & INSTALLATION ACCESSORIES
Product Type:
RESISTOR MODULE
Resistor Value:
10K/10K
Colour:
RED
Minimum Conductor Size:
0.2 mm2 stranded (24AWG)
Maximum Conductor Size:
0.5 mm2 (20AWG)
Dimensions:
24 L x 7 W x 8 H mm
Application:
SECURITY ALARM AND ACCESS CONTROL EOL RESISTOR CIRCUITS
Country of Origin:
China
Series:
ATMOD
Features:
QUICK-CONNECT, PUSH-IN TERMINALS
