JACKFUSE

ATMOD BLACK 1K/1K RESISTOR

SKU: JKFATMOD01 Supplier SKU: ATMOD01
Width:
7.00 (cm)
Height:
8.00 (cm)
Depth:
24.00 (cm)
Minimum Purchase:
48 units

KEY FEATURES

Product Downloads

Description
Download
ATMOD01 Datasheet
ATMOD01 Installation Manual

Please Note: Minimum order quantity (MOQ) 48 units.

ATMOD01 ATMOD End-of-Line Resistor Module - 1K/1K Black

The ATMOD01 is a Jack Fuse ATMOD quick-connect end-of-line resistor module for security alarm and access control circuits. Its pre-built 1K/1K resistor network is housed in a black ATMOD body for straightforward value identification.

Suitable for new installations, service replacements and system upgrades, the module supports faster and more consistent EOL resistor wiring. Push-in spring-clamp terminals allow compatible alarm cabling to be terminated without soldering, crimping or screw terminals.

Key Features

  • Ready-made 1K/1K configuration simplifies component selection for matching EOL requirements
  • Quick-connect format supports efficient termination during installation and maintenance
  • Enclosed resistor network keeps the required components together in one practical module
  • Compact construction supports tidy placement where installation space is limited
  • Suitable for planned project work, system upgrades and ongoing service stock
LIMITED LIFETIME
Catalogue Family:
TOOLS & INSTALLATION ACCESSORIES
Product Type:
RESISTOR MODULE
Resistor Value:
1K/1K
Colour:
BLACK
Minimum Conductor Size:
0.2 mm2 stranded (24AWG)
Maximum Conductor Size:
0.5 mm2 (20AWG)
Dimensions:
24 L x 7 W x 8 H mm
Application:
SECURITY ALARM AND ACCESS CONTROL EOL RESISTOR CIRCUITS
Country of Origin:
China
Series:
ATMOD
Features:
QUICK-CONNECT, PUSH-IN TERMINALS
