UDM-SE UniFi Dream Machine Special Edition - PoE Gateway Console and NVR
The UDM-SE is a UniFi Dream Machine Special Edition all-in-one UniFi OS Console that combines a router, security gateway, integrated PoE switch and network video recorder. It features a 10G SFP+ WAN port, a 2.5 GbE RJ45 WAN port, eight 1 GbE RJ45 LAN ports and dual-WAN support.
Includes 128 GB integrated SSD storage, PoE output, Bluetooth setup support and a 1.3-inch touchscreen. Supports gateway, switching, video recording and UniFi device management in a single rackmount appliance.
Key Features
- Brings routing, security, PoE switching, and NVR functions into one UniFi console.
- Dual-WAN hardware supports resilient internet connection planning.
- Integrated PoE ports reduce the need for a separate small access switch in compact sites.
- Built-in storage supports local video recording workflows without an immediate drive add-on.
- Bluetooth setup and touchscreen status feedback help streamline commissioning and checks.
- Catalogue Family:
- NVR
- Dimensions:
- 442.4 x 43.7 x 285.6 mm
- Weight:
- 4.95 kg
- Enclosure Materials:
- Aluminium CNC / SGCC steel
- Processor:
- Quad-core Arm Cortex-A57 at 1.7 GHz
- System Memory:
- 4 GB DDR4
- On-Board Storage:
- 16 GB eMMC / integrated 128 GB SSD
- Ids/Ips Throughput:
- 3.5 Gbps measured with iPerf3
- Networking Interfaces:
- (1) WAN 2.5 GbE RJ45 port; (8) LAN 1 GbE RJ45 ports
- Sfp+ Interfaces:
- (1) WAN 10G SFP+; (1) LAN 10G SFP+
- PoE Interfaces:
- (2) PoE+ IEEE 802.3at; (6) PoE IEEE 802.3af
- Max. PoE Wattage per Port:
- 15.4W for 802.3af; 30W for 802.3at
- Power Supply:
- AC/DC internal 240W
- Max. Power Consumption:
- 50W excluding PoE output
- Lcm Display:
- (1) 1.3-inch touchscreen
- Operating Temperature:
- -10 to 40°C (14 to 104°F)
- Operating Humidity:
- 5 to 95% noncondensing
- Certifications:
- CE, FCC, IC
- Product Type:
- NVR
