NHU-UDM-SE Ubiquiti UniFi Dream Machine Special Edition 1U Gateway
The NHU-UDM-SE is a UniFi Dream Machine Special Edition rack-mount gateway with integrated UniFi application support for Network, Protect, Access, Talk and Connect. It combines a 1U rack form factor, 10G SFP+ and 2.5 GbE default WAN ports, eight 1 GbE RJ45 ports, two 10G SFP+ ports and a 180 W PoE budget.
It is suited to larger UniFi sites that need gateway, switching, PoE and application hosting functions in one managed appliance. The integrated NVR HDD bay, security services and multi-WAN support make it useful for structured small business, retail, education and security-network deployments.
Key Features
- Combines UniFi gateway, security and application hosting functions in a 1U appliance.
- Integrated PoE switching helps reduce the number of separate devices in the rack.
- 10G SFP+ and 2.5 GbE WAN options support flexible uplink planning.
- Built-in Protect support and HDD bay suit sites using UniFi camera recording.
- Central UniFi management keeps network, access and security services in one ecosystem.
- Catalogue Family:
- NVR
- Form Factor:
- 1U rack mount
- Managed Unifi Devices:
- 100+
- Simultaneous Users:
- 1,000+
- Default WAN Ports:
- (1) 10G SFP+ and (1) 2.5 GbE RJ45
- Port Layout:
- 8 x 1 GbE RJ45, 1 x 2.5 GbE RJ45, 2 x 10G SFP+
- Ids/Ips Throughput:
- 3.5 Gbps
- PoE Budget:
- 180 W
- Processor:
- Quad-core Arm Cortex-A57 at 1.7 GHz
- System Memory:
- 4 GB
- Storage:
- 16 GB eMMC; (1) 3.5 inch NVR HDD bay
- Power Supply:
- 100-240 V AC internal 240 W
- Dimensions:
- 442.4 x 43.7 x 285.6 mm
- Weight:
- 5 kg
- Product Type:
- NVR
