AKRX62-S Airkey 6-Button Input Stand-Alone Receiver
The AKRX62-S is an Airkey 6-button input stand-alone receiver featuring a microcontroller with non-volatile storage and a high-sensitivity PLL-locked 433.92 MHz receiver module. It provides two relay outputs and supports remote learning for Airkey transmitters.
Designed for Airkey remote access systems, the receiver stores up to 340 Airkey transmitters and supports receiver management functions including editing, copying and restoring stored data.
Key Features
- High-sensitivity PLL-locked receiver module provides reliable 433.92 MHz reception.
- Non-volatile memory retains programmed Airkey transmitter data.
- Remote learning function simplifies transmitter enrolment and management.
- Supports storage of up to 340 Airkey transmitters.
- Compatible management tools allow receiver data to be edited, copied and restored.
- Catalogue Family:
- TRANSMITTERS & RECEIVERS
- Model:
- AKRX62-S
- Product Type:
- Transmitters & Receivers
- Input/Output:
- 6 button input, 2 channel output
- Dimensions:
- 105 x 58 x 20 mm
- Weight:
- 52 g
- Receiver:
- 433.92 MHz ASK receiver, -114 dBm sensitivity
- Connections:
- 8-pin screw terminal connections
- Supply:
- 12-28 V AC/DC, approximately 30 mA
- Outputs:
- 2 x SPDT 1 A dry relay contact outputs
- Airkey Slot Capacity:
- 340
