A3043 30 W Mini Class-D Stereo Amplifier - 2 x 15 W RMS
The A3043 is a compact Class-D stereo amplifier with an output of 2 x 15 W RMS into 4 Ω speakers. It supports dynamic microphone and stereo line-level inputs, includes speaker protection circuitry, and is supplied with a 12 V DC power supply.
Designed for compact audio installations, it is suitable for powering a pair of small speakers in music playback, microphone, and line-level audio applications.
Key Features
- Compact enclosure for installations where space is limited
- 2 x 15 W RMS output into 4 Ω speakers
- Supports dynamic microphone and stereo line-level inputs
- Efficient Class-D amplifier design
- Integrated speaker protection circuitry
- Catalogue Family:
- POWER SUPPLY
- Product Type:
- Power Supply
- Output Power:
- 15 W RMS per channel at 4 Ω
- Inputs:
- Dynamic microphone or stereo line-level audio
- Microphone Preamplifier Gain:
- 40 dB
- Thd+n:
- 0.06% at 8 Ω, 1 kHz
- Minimum Speaker Impedance:
- 4 Ω
- Power Source:
- 12 V DC, 2 A
- Speaker Protection:
- Integrated
- Dimensions:
- 93 x 72 x 27 mm
