PP10HD Power Port High Density Power Distribution Module
PP10HD Power Port High Density is a compact power distribution module for electronic security and access control systems. It features ten self-healing fused outputs with status LEDs, double deck terminals, and DIN rail mounting for installation inside security cabinets.
Designed for protected DC power distribution, the module provides ten individually protected outputs with self-resetting PTC fuses. The compact DIN rail design and double deck terminals support efficient wiring in high-density security enclosures.
Key Features
- Ten protected outputs for organised DC power distribution
- Self-healing PTC fuses automatically reset after fault conditions are cleared
- Status LEDs provide visual indication of output status
- Compact DIN rail mounting conserves enclosure space
- Double deck terminals support neat wiring in high-density installations
- Catalogue Family:
- POWER SUPPLY
- Product Type:
- Power Supply
- Input Voltage Range:
- 12-28 VDC
- Fire Relay Coil Voltage:
- 12-28 VDC
- Maximum Standard Power Current:
- 10 A
- Maximum Constant Current per Output:
- 1 A PTC fuse at 20 deg C
- Fused Outputs:
- 10
- Mounting:
- Din Rail
- Dimensions:
- 75 L x 55 W x 55 H mm
- Terminal P1 Maximum Conductor Size:
- 3.3 mm2
