STC-M10/10A Strip Connector 10mm2 Natural 10 Amp
The STC-M10/10A is a natural 12-pole / 2-way strip connector from the MATELEC strip connectors range. It uses a 10 mm2 description, 10 Amp rating, solid brass connector material, 380 V rating and temperature rating up to 90 deg C.
This connector is suited to wiring work where a compact strip connector with dimensions and cable-entry size is required. Its flat-head screw design, flexible body material and clearly specified mounting spacing support practical installation and maintenance selection.
Key Features
- Supports tidy low-voltage or mains-rated terminal termination where the specified strip connector format is required.
- Flexible pliable body material assists handling during installation and wiring work.
- Flat-head screws provide a straightforward termination interface for the connector strip.
- Solid brass connector material is specified in the technical specifications.
- Dimensions and cable-entry data help installers check fit before ordering.
- Catalogue Family:
- TOOLS & INSTALLATION ACCESSORIES
- Product Type:
- Tools & Installation Accessories
- Code:
- STC-M10/10A
- Product:
- 10 mm2 - Natural
- Amp Rating:
- 10 Amp
- Voltage:
- 380 V
- Temperature Rating:
- Up to 90 deg C
- Connector Material:
- Solid brass
- Dimensions:
- 129(L) x 16(H) x 21(W) mm
- Cable Entry:
- 3.8 mm
- Mounting Spacing:
- 11.5 mm
- Packing:
- 10
- Carton Quantity:
- 400
