PBB2P-480W-IEC-48V Powerbox DIN Rail Power Supply with IEC Input - 48 V 10 A 480 W
The PBB2P-480W-IEC-48V is a Powerbox PBB2P Series AC/DC DIN rail power supply with an IEC input and a regulated 48 VDC, 10.0 A output. It provides up to 480 W output power and features a universal 90-264 VAC input range, an IEC input socket with a 2 m IEC power cable, and TS35 DIN rail mounting.
The power supply is designed to provide regulated DC power for industrial control, security, and automation equipment. It uses natural convection cooling, supports full output power from -30 to +50 degrees C with derating up to +70 degrees C, and includes protection functions for overload, overvoltage, and short-circuit conditions.
Key Features
- Provides a regulated 48 VDC, 10.0 A output with up to 480 W maximum power.
- IEC input socket with supplied 2 m IEC power cable simplifies AC power connection.
- Natural convection cooling enables fanless operation.
- Wide operating temperature range supports industrial installations.
- Includes overload, overvoltage, and short-circuit protection functions.
- Output Voltage Range:
- 48 VDC
- Input Voltage Range:
- 90-264Vac
- Type of Device:
- Power Supply
- Product Type:
- Power Supply
