Pro-6-IW AX3000 Wi-Fi 6 In-Wall Access Point
Pro-6-IW is an AX3000 Wi-Fi 6 in-wall access point with dual-band 2.4 GHz and 5 GHz operation, 160 MHz channel width and an aggregate wireless rate up to 3000 Mbps. It supports 2x2 MU-MIMO, OFDMA, beamforming, TWT, 802.11k/v/r roaming, Mesh technology and up to 256 connected clients.
Designed for panel-style WLAN deployment, it provides one Gigabit LAN port with PoE and one additional Gigabit LAN port, allowing wired and wireless access through one installation point. Double-sided tape installation, IPTV penetration, traffic control, WPA3-SAE security and web, controller, cloud platform and app management support modern room-by-room wireless networks.
Key Features
- In-wall form factor supports neat room-level Wi-Fi deployment with local Ethernet access.
- AX3000 dual-band Wi-Fi 6 performance supports high-capacity client connectivity.
- Fast roaming support helps clients move more smoothly across compatible AP networks.
- Mesh support gives installers another option for rapid compatible-device deployment.
- Traffic control tools help balance uplink and downlink use for connected wireless clients.
- Catalogue Family:
- POWER SUPPLY
- Model:
- Pro-6-IW
- Product Type:
- Power Supply
- Application:
- In Wall
- Dimensions:
- 86 x 86 x 32 mm
- Frequency Band:
- 2.4 GHz and 5 GHz
- Wireless Standards:
- IEEE 802.11a/b/g/n/ac/ax
- Data Rate:
- 2.4 GHz: 1-574 Mbps; 5 GHz: 6-2402 Mbps
- Channel Width:
- 20 MHz, 40 MHz, 80 MHz and 160 MHz
- Ethernet Ports:
- 1 x 10/100/1000 Mbps LAN port with PoE; 1 x 10/100/1000 Mbps LAN port
- Power Supply:
- IEEE 802.3af PoE; DC 12 V 1 A
- Connected Clients:
- 256
- Operating Environment:
- -10 to 40°C; 10%-90% RH non-condensing
