ANT433S-N Elsema ANT433S 433 MHz Antenna - 38 cm
The ANT433S-N aligns to the Elsema ANT433S 433 MHz antenna with coaxial cable, mounting bracket and SMA connector.Ground-independent 433 MHz helical whip antenna with a 38 cm whip and a high-grade N-connector base.
Suitable for compatible 433 MHz remote control installations requiring flexible wall or roof mounting. Features a detachable whip, supplied low-loss Cellfoil coaxial cable, and a universal mounting bracket.
Key Features
- 38 cm helical whip design provides a practical mid-size antenna option.
- N-connector base allows the whip to be removed from the mounting base.
- 4.5 dBi gain supports stronger 433 MHz system performance than small whip options.
- Included low-loss coaxial cable and mounting bracket simplify external installation.
- SMA termination suits compatible Elsema 433 MHz equipment.
- Catalogue Family:
- CABLE
- Model:
- ANT433S
- Frequency:
- 425.00 to 442.50 MHz
- Tuned Bandwidth:
- 17.50 MHz
- Gain:
- 4.5 dBi
- Vswr:
- < 1.5:1 over 15 MHz
- Impedance:
- 50 ohms
- Length:
- 38 cm
- Coaxial Length:
- 3.6 m standard with N-connector base
- Termination:
- SMA
- Product Type:
- Cable
