101-201 ELK M1 Gold Security and Automation Control Module
The 101-201 is an ELK M1 Gold security and automation control module. It supports intrusion, medical, and environmental monitoring, telephone dialling, keypad connection, wireless expansion, and automation functions within the ELK M1 system.
The control module supports expandable zones, multiple user codes, partitions, access-control points, and optional communication or interface modules for reporting and remote system access.
Key Features
- Combines security control and automation logic in the M1 Gold platform
- Expandable zone and output capacity supports larger integrated installations
- Rules-based automation enables linked security and device-control outcomes
- Keypad, wireless and access-control support help tailor the system to site needs
- Optional communication interfaces extend reporting and remote-access pathways
- Catalogue Family:
- PIRS
- Platform:
- M1 Gold security and automation controls
- On-Board Zones:
- 16
- Expandable Zones:
- Up to 208
- Wireless Capability:
- Up to 144 zones
- On-Board Outputs:
- 13
- Total Outputs Supported:
- 205
- Partitions:
- Up to 8 areas
- User Codes:
- 199
- Maximum Keypads:
- 16
- Access Control:
- Up to 16 points
- Product Type:
- PIR Sensor
