TZ606WWP TOA TZ-606WWP Weatherproof Column Speaker - 60 W White
The TOA TZ-606WWP is a weatherproof column speaker in the TZ Series. It features a 60 W rated input, six 10 cm waterproof cone-type speaker units, IP65 weatherproof rating, push-in terminals and a white weatherproof column speaker configuration.
Its vertical array is designed to widen horizontal coverage while limiting vertical dispersion, helping improve intelligibility in reverberant spaces and outdoor venues. Adjustable brackets and selectable impedance taps support practical installed audio setup.
Key Features
- Column array design helps focus sound for clearer speech coverage.
- IP65 weatherproof construction supports appropriate outdoor applications.
- Selectable wattage taps help match the speaker to the amplifier design.
- Push-in terminals support faster wiring during installation.
- Bracket adjustment helps aim coverage after mounting.
- Catalogue Family:
- SOUND & PUBLIC ADDRESS
- Product Type:
- Sound & Public Address
- Rated Input:
- 60 W
- Rated Impedance:
- 100 V line: 170 ohm (60 W), 330 ohm (30 W), 670 ohm (15 W), 1.3 kohm (7.5 W)
- Sensitivity:
- 94 dB (1 W, 1 m)
- Frequency Response:
- 150 Hz to 13 kHz
- Speaker Component:
- 10 cm cone-type x 6, waterproof
- Input Terminal:
- Push-in terminal
- IP Code:
- IP65
- Dimensions:
- 135 (W) x 746 (H) x 128 (D) mm
- Weight:
- 5.5 kg
