RD1000 RollUPS Single Phase UPS for Motor Loads - 1000W
The RD1000 is a RollUPS single phase UPS for motor loads up to 0.65hp / 484W, with a maximum output of 1000W. It includes sleep mode, generator compatibility, intelligent battery management, full-time surge protection, cold start and protection against short circuit and low battery voltage.
It is designed for automated door and motor-control environments where standby power helps maintain operation during outages. The RD1000 uses a compact standalone format with two Australian outlets and standby-time guidance for opening-cycle planning.
Key Features
- Supports backup power planning for smaller single-phase motor loads.
- Sleep mode helps preserve standby readiness for door-control applications.
- Provides cold-start capability where mains power is unavailable.
- Combines motor-focused UPS protection with local status feedback.
- Uses a compact enclosure for installations that do not need rack mounting.
- Catalogue Family:
- UPS
- Recommended Motor Capacity:
- Motors to 0.65hp / 484W with sleep mode
- Maximum Output:
- 1000W
- Input Voltage:
- 230V +/- 25%
- Input Cable:
- Aus 10A
- Battery Configuration:
- 2 x 12V 9Ah
- Outlets:
- 2 Australian outlets
- Dimensions (H X W X D):
- 408 x 197 x 143mm
- Weight:
- 10.9kg
- Standby Time:
- 40 minutes
- Product Type:
- UPS
