PR115B External Smart Card LAN Reader - Black
The Bosch PR115B is a black external smart card LAN reader for selected Bosch Solution security control panels. It uses high-security encrypted two-way authentication and connects to the control panel through an encrypted RS485 LAN.
Constructed from UV-stabilised ASA plastic, the reader is vandal resistant and rated IP66 for weather-resistant outdoor installation. It can be configured for alarm area control, door access control or both, depending on the panel programming and installation requirements.
Key Features
- IP66 vandal-resistant and weather-resistant construction for outdoor installation.
- High-security encrypted two-way authentication transmission format.
- Encrypted RS485 LAN connection to compatible Bosch Solution control panels.
- Red, green and blue indicators display area and door-lock status.
- Built-in sounder provides system-event and alarm feedback.
- Includes an egress input and protected lock output for door-control integration.
- Supports alarm control, access control or combined alarm and access control operation.
- Catalogue Family:
- LOCKING
- Product Type:
- Locking
- Model and Colour:
- PR115B - Black
- Construction:
- UV-stabilised ASA plastic; vandal and weather resistant
- Ingress Protection:
- IP66
- Credential Format:
- Smart Card (MIFARE), proprietary 40-bit format, 10.3 MHz
- Panel Connection:
- Encrypted RS485 LAN
- Operating Voltage:
- 10.0 V DC to 14.5 V DC at 100 mA maximum
- Lock Output:
- Protected open-collector transistor output, 500 mA
- Egress Input:
- Low-to-trigger; can be disabled through panel programming
- Dimensions:
- 44 mm W × 21 mm D × 114 mm H
- Operating Environment:
- -30°C to 55°C; 5% to 85% RH at 30°C, non-condensing
- Compatible Panels:
- Solution 16i version 2.19 or later; Solution 144 version 2.00 or later; Solution 6000 version 2.12 or later
- Warranty:
- 3 years from date of manufacture, return to base
