IX-DB Aiphone IX Series IP Video Door Station - Surface Wall Mount
The IX-DB is an Aiphone IX Series IP video door station for surface wall-mounted entry points. It operates from Power-over-Ethernet, provides hands-free communication and uses a 1/3.2 in colour CMOS camera with H.264/AVC or Motion JPEG video.
It suits networked visitor screening where a compact plastic video door station is needed for a doorway, reception point or controlled access location. The station supports Ethernet networking, SIP and ONVIF Profile S video integration, 20 called stations, a relay output for electric lock control and IP54 / IK07 protection.
Key Features
- Surface wall-mount format keeps the station practical for straightforward entry installations.
- PoE operation reduces the need for a separate local power supply at the door station.
- Hands-free visitor communication supports clear entry conversations at the access point.
- SIP and ONVIF Profile S support help the unit fit into broader IP security workflows.
- Compact ABS construction suits controlled entrances where a lightweight video station is preferred.
- Catalogue Family:
- INTERCOM
- Model:
- IX-DB
- Product Type:
- INTERCOM
- Power Source:
- POWER-OVER-ETHERNET, IEEE 802.3AF CLASS 0
- Current Consumption:
- Standby 35 mA, maximum 80 mA
- Communication:
- HANDS-FREE
- Camera:
- 1/3.2 in colour CMOS camera
- Minimum Illumination:
- 5 lux
- LAN:
- Ethernet 10BASE-T / 100BASE-TX
- Audio Codec:
- G.711
- Video Codec:
- H.264/AVC, Motion JPEG
- Number of Called Stations:
- 20 stations
- Operating Temperature:
- -10 TO +60 DEG C (+14 TO +140DEGREE)
- Mounting:
- WALL MOUNT
- Electrical Box:
- Single-gang box
- Material:
- PLASTIC
- Colour:
- BLACK/SILVER
- Weight:
- Approx. 290 g (0.64 lb)
- IP Rating:
- IP54
- IK Rating:
- IK07
- ONVIF Support:
- ONVIF Profile S support
- Relay Output:
- Form C dry contact, N/O or N/C, 24V AC/DC 0.5A resistive load
- Dimensions:
- 130 mm H x 97 mm W x 42 mm D
- Series:
- IX SERIES
