HEX70CS-KIT HDBaseT™ CSC Extender Kit
The HEX70CS-KIT is an HDMI 2.0 4K 60Hz 4:4:4 HDCP 2.2 HDBaseT™ extender set using Colour Space Conversion technology. It extends HDMI, bi-directional IR, RS-232 and bi-directional PoH up to 70 m, with 4K extension supported up to 40 m.
The transmitter includes HDMI loop-out for a local display or cascade path, while the receiver provides simultaneous analogue stereo and coaxial digital audio breakout. This makes the kit practical for custom AV installations that need source extension, local monitoring and control over a single CAT cable.
Key Features
- Extends high-resolution HDMI with control signals through one structured cable run.
- CSC support helps integrate 18Gbps HDMI 2.0 sources over HDBaseT™ infrastructure.
- Transmitter loop-out supports local viewing or cascading without an extra splitter.
- Receiver audio breakout gives installers more options for local audio integration.
- Bi-directional control paths support coordinated source, display and system operation.
- Catalogue Family:
- POWER SUPPLY
- Model:
- HEX70CS-KIT
- Product Type:
- Power Supply
- Video Support:
- HDMI 2.0 18Gbps, 4K 60Hz 4:4:4 and HDR via CSC
- Transmission Distance:
- 4K 60Hz 4:4:4 up to 40 m; HDMI 1080p up to 70 m
- Transmitter Connections:
- HDMI input, HDBaseT™ output, HDMI loop-out, RS-232, IR and EDID DIP switch
- Receiver Outputs:
- HDMI, coaxial digital audio and analogue L/R audio
- Control Support:
- Bi-directional IR and RS-232 pass-through
- Transmitter Dimensions:
- 143 x 134 x 22 mm
- Receiver Dimensions:
- 113 x 124 x 22 mm
- Power Supply:
- 12 V/2 A DC
