FS-3500E UV Flame Sensor With Voice Message
The FS-3500E is a TAKEX ultraviolet flame sensor that detects UV rays from a flame and outputs recorded warning messages. It is designed for indoor installations and can announce fire-prohibition or non-smoking messages in selectable languages.
The sensor suits areas where early flame detection needs to trigger a local audible warning as well as a signal output. Battery or external DC power options, adjustable sensitivity, selectable timer settings and tamper output give installers a practical flame-warning device for controlled indoor spaces.
Key Features
- Detects ultraviolet flame energy and links it to recorded warning messages.
- Supports both non-smoking and fire-prohibition message selections.
- Allows sensitivity and detection timer settings to be matched to the environment.
- Can operate from AA alkaline batteries or external DC wiring.
- Provides selectable signal output and tamper output for system integration.
- Catalogue Family:
- ALARM SENSOR
- Model:
- FS-3500E
- Product Type:
- Alarm Sensor
- Detection System:
- Ultraviolet rays detection, 185 to 260 nm
- Detection Distance:
- 10 m for 7 cm flame
- Detection Angle:
- 120 degrees conically
- Detection Sensitivity:
- 2 levels: high 100 percent and low 50 percent
- Detection Timer:
- 1 sec., 3 sec., 6 sec., 15 sec.
- Power Supply:
- 2 x AA alkaline batteries / DC 3 V included; external wiring DC 10 V to 30 V polarized
- Power Consumption:
- External DC standby 40 mA or less; alarm 300 mA or less
- Signal Output:
- Relay contact output N.O./N.C. selectable; DC 30 V 0.1 A
- Messages:
- 5 languages; non-smoking or fire-prohibition message; repeat once or twice selectable
- Ambient Temperature:
- -10 degrees C to +60 degrees C without condensation
- Installation:
- Indoor
- Appearance:
- White ABS resin
