BS-1030W TOA Universal Speaker - White
The BS-1030W is a white TOA BS-1030 Series 2-way bass reflex universal speaker for paging and background music. It supports 30 W rated input, 8 ohm low-impedance use and 70 V/100 V line operation with selectable tap settings, using a 12 cm cone driver and 2.5 cm balanced dome tweeter.
Its compact ABS resin enclosure, steel grille and adjustable bracket make it suitable for commercial wall audio installations. IP-X4 splash-resistant construction supports sheltered outdoor placement where the speaker is not directly exposed to the elements.
Key Features
- Combines paging and background music coverage in a compact wall speaker format.
- Selectable tap and impedance settings help one model suit distributed line or low-impedance systems.
- Two-way bass reflex design supports clearer speech and music reproduction.
- White enclosure and grille help the speaker sit discreetly in light interiors.
- Splash-resistant construction supports sheltered outdoor audio locations.
- Catalogue Family:
- SPEAKERS
- Model:
- BS-1030W
- Speaker Type:
- 2-way bass reflex universal speaker
- Rated Input:
- 30 W
- Impedance:
- 8 ohm; 100 V line taps 330 ohm, 500 ohm, 670 ohm, 1 kohm, 2 kohm; 70 V line taps 170 ohm, 250 ohm, 330 ohm, 500 ohm, 1 kohm
- Sensitivity:
- 90 dB (1 W/1 m, anechoic chamber)
- Frequency Response:
- 80 - 20,000 Hz
- Speaker Components:
- 12 cm dynamic cone speaker; 2.5 cm balanced dome tweeter
- Water Resistance:
- IP-X4
- Operating Temperature:
- -10 C to +50 C
- Material and Finish:
- ABS resin enclosure white paint; surface-treated steel grille and bracket white powder coating
- Dimensions:
- 196 W x 290 H x 150 D mm without bracket
- Weight:
- 2.5 kg without bracket
- Product Type:
- Speakers
