X-410-E Web-Enabled Programmable Controller
The X-410-E is a web-enabled programmable controller with four relays, four digital inputs and a 1-Wire bus supporting up to 16 sensors. It features PoE and/or 9-28 VDC power, one 10/100 Base-T Ethernet port, a removable 14-terminal connector and relay, input, counter, timer and sensor monitoring functions.
Supports control and monitoring over TCP/IP networks using a web browser, mobile app or custom applications. Compatible with HTTP, HTTPS, XML, Modbus TCP/IP, SNMP, SMTP and remote services. Includes built-in tasks, scheduling, logging and BASIC scripting.
Key Features
- Four relay outputs, four digital inputs and 1-Wire support for up to 16 sensors
- Supports PoE and 9-28 VDC power input
- Compatible with HTTP, HTTPS, XML, Modbus TCP/IP, SNMP, SMTP and remote services
- Built-in tasks, scheduling, logging and BASIC scripting
- DIN-rail or wall-mountable enclosure
- Catalogue Family:
- ACCESSORIES
- Model:
- X-410-E
- Product Type:
- ACCESSORIES
- Power:
- POE AND/OR 9-28 VDC
- Maximum Current:
- 240 mA
- Relays:
- 4 electro-mechanical relays, shared common
- Digital Inputs:
- 4 non-isolated inputs, 4-26 VDC range
- 1-Wire Support:
- Up to 16 sensors
- Network:
- 10/100 Base-T Ethernet port
- Protocols:
- HTTP, HTTPS, SSL, XML, Modbus TCP/IP, SNMP, SMTP, Remote Services
- Operating Temperature:
- -40 C TO 65.5 C
- Size:
- 35.7 MM WIDE X 98.5 MM TALL X 78 MM DEEP, NOT INCLUDING CONNECTOR
- Enclosure Material:
- LEXAN 940 POLYCARBONATE PLASTIC, UL94 V0 FLAME RATING
- Compliance:
- X-410-E: FCC 47CFR15 Class A; UL 61010-1 product safety compliance
