WAC24-8A 24V AC Wall Mounted Power Supply - 8.2A
The WAC24-8A is a 24V AC wall mounted power supply for low-voltage distribution, with an 8.2A rated current and 16 fused terminal outputs. The unit combines a lockable enclosure format with LED voltage display, battery backup provision, an internal GPO recess and LED indication for output circuits.
It suits security, access control and automation installations that need serviceable 24V AC distribution from a single wall-mounted supply. Short circuit and overload protection, free-air convection cooling and a wide wide operating temperature range support dependable use in equipment rooms and site power locations.
Key Features
- Centralises 24V AC distribution in a lockable wall-mount format.
- Helps technicians identify circuit status quickly through local indication.
- Supports protected low-voltage supply layouts for multi-output installations.
- Uses user-replaceable fused outputs to simplify service work.
- Designed for broad site conditions with a -20 to 70 deg C working range.
- Output Voltage Range:
- 24 VAC
- Input Voltage Range:
- 192-264Vac
- Type of Device:
- Power Supply
- Product Type:
- Power Supply
