TANTANE-45-WH Tane TANE-45 Miniature Super Stick Surface Mount Contact - White
The Tane TANE-45 is a miniature surface mount contact with Super Stick adhesive. It features a 1.06 in x 0.27 in x 0.19 in contact and magnet size, 0.44 in standard gap, 12 in 22 AWG leads and white or brown colour options.
Its very small body supports discreet alarm contact installation where a recessed device is not practical. The low contact rating and AC24/DC24 switching limit are kept explicit in the specs version so buyers can match it to a suitable circuit.
Key Features
- Miniature surface mount body helps reduce visual impact on frames.
- Adhesive mounting supports simple placement without a recessed cavity.
- Matched contact and magnet dimensions help maintain a tidy installation.
- Factory lead detail supports direct alarm-circuit connection.
- Clear low-power ratings support safe product selection.
- Catalogue Family:
- ALARM SENSOR
- Product Type:
- Alarm Sensor
- Contact Size:
- 1.06 in x 0.27 in x 0.19 in (26.9 x 6.85 x 4.75 mm)
- Standard Magnet Size:
- 1.06 in x 0.27 in x 0.19 in (26.9 x 6.85 x 4.75 mm)
- Standard Gap:
- 0.44 in (11 mm)
- Loop / Reed Form:
- Closed loop / normally open
- Max. Contact Rating:
- 1 W
- Max. Switching Voltage:
- AC24/DC24 V
- Max. Switching Current:
- 0.1 A
- Leads:
- 12 in (305 mm) 22 AWG leads
- Operating Temperature:
- -40 deg C to +60 deg C
- Colour:
- White
- Device Type:
- REED SWITCH
- Display:
- NONE
- Mounting:
- Surface Mount
- Output:
- 1 OUTPUT
- Wiring:
- Hardwired
