CM368B IP Combo Module - 4G and 3G LTE CAT 1 with Ethernet
The CM368B is an IP communication module that connects compatible security control panels to 4G/3G LTE cellular networks and includes a wired Ethernet port for dual-path alarm reporting.
Designed for Solution 6000 and Solution 6000-IP control panels, the module supports GPRS and Ethernet reporting, SMS messaging and multiple IP reporting formats. It mounts directly to the control panel expansion port and uses a standard full-size SIM card installed in the SIM 1 socket.
Key Features
- Dual-path cellular and Ethernet communication supports reliable alarm reporting.
- Supports multiple reporting formats across GSM, GPRS and Ethernet networks.
- Compatible with supported Solution 6000 and Solution 6000-IP firmware versions.
- 128-bit AES encryption helps secure IP reporting communications.
- Direct expansion-port mounting provides seamless integration with the control panel.
- Catalogue Family:
- ALARM / INTRUSION
- Compatible Panels:
- Solution 6000 firmware V2.51.04; Solution 6000-IP firmware V3.00.00
- Network Interface:
- RJ45 Ethernet 10BASE-T or 100BASE-T, auto sensing
- Encryption:
- 128 bit AES
- Reporting Formats:
- SMS via GSM; CSV-IP, Conettix, SIA IP and MyAlarm formats via GPRS and Ethernet
- Radio:
- 4G Quectel EG91 CAT-1 network with 3G fallback
- SIM Card Type:
- Standard full-size SIM installed in SIM 1 socket
- Antenna:
- Quad band omni directional magnetic mount antenna with integrated lead and SMA connector, 3 dBi gain, 50 ohm
- Operating Environment:
- 0 to 55 C, RH 5 to 85% at 30 C non-condensing
- Module Connection:
- Mounted directly to the expansion port on the control panel PCB
- Product Type:
- Alarm / Intrusion
