41019 Audio Video Module Alphanumeric Keypad
41019 is an alphanumeric keypad module for Elvox audio-video entrance-panel modules. It provides white LED backlit keys, audible feedback, an input configurable for CA or PA door-open functions, and a programmable normally open auxiliary relay output.
Used with 41000 series speech units, the keypad enables code-based entry control and direct extension calling when a compatible display module is fitted. Harness power from the connected audio/video or audio module keeps the module aligned with the surrounding Pixel panel electronics.
Key Features
- Enables personal-code entry control directly from the entrance panel.
- Supports direct extension calling when paired with a compatible display module.
- Backlit keys improve readability for visitors at the panel.
- Programmable auxiliary contact supports additional system functions.
- IP54 and IK08 Pixel ratings support use in robust modular panel assemblies.
- Catalogue Family:
- INTERCOM
- Product Type:
- INTERCOM
- Backlighting:
- White LED
- Power Supply:
- FROM AUDIO/VIDEO OR AUDIO MODULE VIA HARNESS
- Current Draw:
- 90 MA
- Operating Temperature:
- -25 DEG C TO +55 DEG C
- Protection Class:
- IP54
- Impact Rating:
- IK08 for Pixel
- Auxiliary Output:
- N/O contact, 1 A max, 60 Vdc max SELV
- Code Length:
- Maximum 8 digits
- Colour:
- WHITE
- Device Type:
- KEYPAD MODULE
- Display Size:
- NONE
- Features:
- REQUIRES KEYPAD FACEPLATE
- Mounting:
- RECESSED MOUNT
- Power:
- POWER BY BUS CONTROLLER
- Series:
- PIXEL/ HEAVY DUE FILI+
- Solution:
- APARTMENT,COMMERCIAL
- Technology:
- 2-WIRE
