CZ1000 Cable Pair Identifier F-Set
The CZ1000 is a cable pair identifier set for locating conductors in multipair cabling applications. It includes a transmitter and search probe, with warble-tone identification, line polarity indication, an inbuilt loudspeaker, a continuity buzzer, and a modular plug and clips lead set.
Suitable for data and communications cable tracing, the set provides end-to-end cable pair identification with continuity confirmation when the identified pair is shorted. A carry case is included for field use and transport.
Key Features
- Transmitter and search probe for cable pair identification.
- Warble-tone output for efficient cable tracing.
- Continuity buzzer confirms identified cable pairs.
- Line polarity indication with inbuilt loudspeaker.
- Includes a modular plug and clips lead set and carry case.
- Catalogue Family:
- INSTALLATION TOOLS
- Product Type:
- Installation Tools
- Set Components:
- Transmitter and search probe
- Tone Frequency:
- 1.5 kHz to 2.1 kHz
- Protection:
- 240V AC, 350V DC
- Continuity:
- <35 kOhm
- Probe Sensitivity:
- 46 dB gain input to earpiece
- Physical Dimensions:
- 240 x 150 x 36 mm packed unit
- Weight:
- 500 g
- Batteries:
- 2 x LR6 AA 1.5V and 1 x 6LR61 9V
