CR2-BATTERY Panasonic CR2 3V Cylindrical Lithium Battery
The CR2-BATTERY is a Panasonic CR2 cylindrical lithium battery with a 3 V nominal voltage and an 850 mAh nominal capacity. It uses manganese dioxide chemistry in the positive electrode and is designed in the standard CR cylindrical battery format.
Designed for compact battery-powered devices, the battery features a maximum diameter of 15.6 mm and a maximum height of 27.0 mm. It is suitable for applications requiring the CR2 battery size, including compatible security devices.
Key Features
- CR2 cylindrical lithium format supports compact device battery replacement.
- 3 V nominal voltage and 850 mAh nominal capacity provide clear selection references.
- 15.6 mm maximum diameter and 27.0 mm maximum height help confirm device compatibility.
- Suitable for high-rate discharge applications.
- Compatible with security devices and other equipment requiring a CR2 battery.
- Catalogue Family:
- BATTERY
- Model:
- CR2
- Battery Type:
- Cylindrical lithium battery
- Nominal Voltage:
- 3V
- Nominal Capacity:
- 850 mAh
- Continuous Drain:
- 20 mA
- Diameter:
- 15.6 mm max.
- Height:
- 27.0 mm max.
- Weight:
- Approx. 11.0 g
- Operating Temperature:
- -40 deg C to +70 deg C
- Product Type:
- Battery
