A3217C HDMI And Infra-Red Cat5e Cat6 Extender UTP Balun - 50 m 1080p
The A3217C is an HDMI and infra-red Cat5e/6 extender balun set for sending a 1080p HDMI source up to 50 m over a single UTP cable. It includes one transmitter and one receiver, loop HDMI output on the transmitter, EDID copy support and bi-directional IR extension.
It is suited to AV installations where the HDMI source is located away from the display but a local loop output or IR control path is still needed. The 1080p and 50 m performance range makes it practical for straightforward long-distance HDMI distribution.
Key Features
- Extends 1080p HDMI over economical Cat5e/6 cabling for longer AV runs.
- Loop HDMI output on the transmitter supports local viewing at the source end.
- Bi-directional IR allows remote-control signals to travel with the HDMI extension.
- EDID reading and saving helps improve display-source negotiation in fixed installs.
- Transmitter and receiver package gives a matched point-to-point extension set.
- Catalogue Family:
- POWER SUPPLY
- Model:
- A3217C
- Product Type:
- Power Supply
- Transmission Distance:
- 1080p up to 50 m under stated conditions
- Resolution Outputs:
- 1080p, 1080i, 720p, 576p and 480p
- Data Transfer Speed:
- 6.75 Gbps
- Cable:
- Single Cat5e/6 cable
- Transmitter Connectors:
- 2 x HDMI receptacle, 1 x RJ45, 1 x DC power, 2 x IR
- Receiver Connectors:
- 1 x HDMI receptacle, 1 x RJ45, 1 x DC power, 2 x IR
- Power Supply:
- DC 5 V
- Power Consumption:
- 3.5 W max
- IR Wavelength and Frequency:
- 940 nm, 38 kHz to 56 kHz
- Package Contents:
- 1 x transmitter, 1 x receiver, 2 x IR TX emitters, 2 x IR RX receivers, 2 x 5 V / 1 A DC adapters and user manual
