DH-SD4D425MB-HNR Dahua WizSense Xinghan 4MP Starlight Smart Dual Illumination Network PTZ Camera - 25x Optical Zoom
The Dahua DH-SD4D425MB-HNR uses a 1/2.8-inch CMOS sensor to produce up to 4MP 2560 x 1440 video at 25/30 fps. Its 5-125 mm motorised lens provides 25x optical zoom, supported by endless 360-degree pan movement and a -15-degree to +90-degree tilt range with automatic 180-degree flip.
Smart dual illumination provides infrared coverage up to 100 m and warm-light coverage up to 50 m, while 120 dB WDR and electronic image stabilisation support varied monitoring conditions. The IP66-rated camera operates from -40°C to +70°C and includes 12 VDC or PoE+ power, audio input and output, two alarm inputs, one alarm output and MicroSD storage up to 512 GB.
Key Features
- AutoTracking 3.0 controls pan, tilt and zoom to keep a moving target within view
- AcuPick works with supported back-end devices to locate human and vehicle targets in live and recorded footage
- Auto Patrol links IVS target detection with PTZ positioning and preset-based patrol
- SMD 4.0 classifies motion targets while filtering unrelated objects to reduce false alarms
- Face detection supports attribute extraction and real-time, quality-priority and preferred-image snapshots
- Product Type:
- CAMERA
- Catalogue Family:
- CAMERA
- Megapixels:
- 4MP
- Camera Body:
- PTZ CAMERA
- IP Rating:
- IP66
- Series:
- WIZSENSE
- Technology:
- IP
- Colour:
- WHITE
- AI:
- SMD 4.0
- Special #1:
- ACUPICK
- Special #2:
- AUTO TRACKING
- Compression:
- H.264/5/5+/ MJPEG
- Dynamic Range:
- 120WDR
- Lens Size:
- 5-125MM
- Lens Type:
- MOTORIZED VARI-FOCAL LENS
- Zoom:
- 25X ZOOM
- Nightvision:
- STARLIGHT
- Infra Type:
- IR+WARM LED
- IR Distance:
- 100M
- Type of PoE:
- POE+
- Built-in Microphone:
- WITHOUT MIC
- Audio In:
- 1 CHANNEL
- Audio Out:
- 1 CHANNEL
- Alarm In:
- 2 x ALARM IN
- Alarm Out:
- 1 x ALARM OUT
- SD Card:
- UPTO 512GB SD
- Voltage:
- 12VDC
- Built-In Speaker:
- WITHOUT SPEAKER
- Network/Connection Type:
- RJ45 ETHERNET
- Pan Range:
- 360°
- Tilt Range:
- 90°
- Privacy Masking:
- UP TO 32 AREAS
- Operating Temperature:
- -40 °C TO +60 °C
