NEDAP-N-U-WSS-TP-CUSTOM uPASS UHF Windshield Tag Custom Programming
The NEDAP-N-U-WSS-TP-CUSTOM is a UHF Windshield Tag variant for long-range vehicle identification. It uses a passive, battery-free UHF tag format with EPC Gen 2 compatibility, windshield mounting and custom programming / customised printing options.
It is a passive, battery-free UHF tag with EPC Gen 2 compatibility, windshield mounting, custom programming and customised printing options.
Key Features
- Passive UHF technology avoids tag battery maintenance in vehicle access use.
- Windshield sticker format supports simple in-vehicle installation.
- Customisation options help align tag layout and programming to site needs.
- Tamper-resistant construction gives visual indication if removal is attempted.
- Reader compatibility supports use with Nedap uPASS reader systems.
- Catalogue Family:
- ACCESSORIES & OTHERS
- Product Type:
- ACCESSORIES & OTHERS
- Custom Part Reference:
- 9946918 UHF Windshield Tag Custom Programming
- Custom Tag Dimensions:
- 90 x 27 mm
- Colour:
- WHITE
- Weight:
- 1 g
- Protection Class:
- IP54 APPROX. NEMA 2
- Material:
- POLYESTER FOR 9946918 CUSTOM PROGRAMMING REFERENCE
- Operating Temperature:
- -20 TO +70 DEG C
- Read Range:
- UP TO 15 M WITH UPASS TARGET; UP TO 10 M WITH UPASS GO
- Operating Frequency:
- 865-870 MHZ / 902-928 MHZ
- Mounting:
- PRESSURE-SENSITIVE ADHESIVE BACK FOR WINDSHIELD MOUNTING
- Standards:
- EPC Gen2
