HID-2060 HID iCLASS 2K Adhesive Smart Tag
The HID-2060 is an HID iCLASS 13.56 MHz contactless smart adhesive tag with 2K-bit memory. It is a read/write smart tag designed for adding iCLASS technology to compatible non-metallic objects.
It suits deployments where an existing badge or non-metallic item needs to become an iCLASS credential. The small adhesive form factor supports practical upgrades while retaining iCLASS encryption, application areas and reader compatibility.
Key Features
- Adhesive tag format helps upgrade suitable items into iCLASS credentials.
- 13.56 MHz iCLASS technology supports read/write smart-card access control.
- 2K bit memory provides two application areas for credential use.
- Compact tag design is useful where a full card is not the best format.
- Factory or field programming support helps align the tag to existing HID formats.
- Catalogue Family:
- CARDS
- Credential Type:
- iCLASS contactless smart adhesive tag
- Operating Frequency:
- 13.56 MHz
- Memory:
- 2K bit / 256 Byte with 2 application areas
- Dimensions:
- 32 mm diameter x 1.78 mm thickness
- Operating Temperature:
- -40 deg C to 70 deg C
- Operating Humidity:
- 5% to 95% non-condensing
- Product Type:
- Card / Fob
