CAPBP2250 Non-Polarised Bipolar Capacitor - 22 uF 50 V
The CAPBP2250 is a non-polarised bipolar PCB-mount capacitor with a capacitance of 22 uF and a 50 V DC rating. It features a radial lead design and offers excellent frequency characteristics, low leakage current, a low dissipation factor, and an operating temperature range of -40°C to +85°C.
Designed for electronic repairs, audio crossover networks, and general electronic circuits, the radial lead construction and non-polarised design make it suitable for applications requiring bipolar capacitance.
Key Features
- Non-polarised bipolar design for AC signal and audio crossover applications
- Radial lead PCB-mount construction for straightforward installation
- 22 uF capacitance with a 50 V DC rating
- Low leakage current and low dissipation factor
- Compact 8 mm diameter body for space-constrained PCB layouts
- Catalogue Family:
- INTERCOM
- Product Type:
- Intercom
- Capacitance:
- 22 uF
- Rated Voltage:
- 50 V DC
- Ripple Current:
- 82 mA
- Diameter:
- 8 mm
- Lead Pitch:
- 3.5 mm
- Height:
- 11 mm
- Operating Temperature:
- -40°C to +85°C
- Surge Voltage:
- 63 V
- Tolerance:
- ±20%
