ATMOD68 ATMOD End of Line Resistor Module - 2K2/6K8 Blue
The ATMOD68 is a Jack Fuse ATMOD quick-connect End of Line resistor module for security alarm and access control circuits. It features a pre-built 2K2/6K8 resistor network housed in a blue colour-coded ATMOD module.
Designed for new installations, service replacements and system upgrades, the module uses push-in spring clamp terminals for fast cable termination without soldering, crimping or screw terminals.
Key Features
- Quick-connect End of Line resistor module for security alarm and access control systems.
- Blue colour-coded housing for easy identification of the 2K2/6K8 resistor value.
- Pre-built resistor network simplifies installation and replacement.
- Compact insulated design fits inside devices, door frames and cable ducts.
- Reusable push-in spring clamp terminals for fast cable termination and servicing.
- Catalogue Family:
- TOOLS & INSTALLATION ACCESSORIES
- Product Type:
- Tools & Installation Accessories
- Resistor Value:
- 2K2/6K8
- Colour:
- Blue
- Minimum Conductor Size:
- 0.2 mm2 stranded (24AWG)
- Maximum Conductor Size:
- 0.5 mm2 (20AWG)
- Dimensions:
- 24 L x 7 W x 8 H mm
- Application:
- Security alarm and access control EOL resistor circuits
- Country of Origin:
- China
