2616EMC Lockwood Electromechanical Hold-Open Device - Single Door 24 VDC
The 2616EMC is a Lockwood single-door electromechanical hold-open device with a sliding arm. It operates on 24 VDC with 60 mA current consumption, features an adjustable hold-open angle from 70 degree to 130 degree, supports push-side or pull-side installation, suits 40 mm narrow frames, and is fire tested to AS1905.1:2005 Part 1.
Key Features
- Single-door hold-open function helps keep fire doors open during normal building use.
- Power-off release supports automatic door closing when connected fire detection removes power.
- Adjustable hold-open angle gives installers flexibility during commissioning.
- Push-side and pull-side suitability supports a wider range of door closer installations.
- Fire-tested design supports use in appropriate fire door assemblies.
- Catalogue Family:
- LOCKING
- Product Type:
- Locking
- Voltage:
- 24 VDC +/- 15%
- Power Consumption:
- 60 mA per hold-open device
- Maximum Door Width:
- 1400 mm
- Opening Angle:
- 70 degrees to 130 degrees
- Maximum Opening Angle:
- 130 degrees
- Frame Suitability:
- Narrow frames from 40 mm
- Installation Sides:
- Push side or pull side
- Fire Testing:
- Up to 4 hours to AS1905.1:2005 Part 1
